Robotics Two Switch Box Enclosure Case Without Button

This is Robotics Switch Box Enclosure Without DPDT Switches.

The switch box is used to accommodate two DPDT Rocker Switches. It is a perfect makeshift remote for your robot.

This is a Remote Control Box for Wired Hobby Robot Control. To make the anti-clockwise motion of the motor, the polarity of supply must be inverted in a clockwise motion. For “Polarity Reversal” DPDT switches are generally used.

A Double Pole Double Throw (DPDT) switch is an electromechanical switch that has 2 inputs and 4 outputs and each input has 2 corresponding outputs that it can connect to.

Applications

• Remote-controlled robot.
• AVR-based robotics projects.
• ARM-based robotics projects.
• PIC-based robotics projects.
• Arduino-based robotics projects.
• Raspberry-pi-based robotics projects.
• Android-based robotic projects.

---

Features :

1. Homopolymer.
2. Good Processability.
3. Good Impact Resistance.
4. Good Stiffness.
5. Switched will directly snap-fit into slots.
6. For Linear Actuators and other DC Motors
